Titan 55kVA Three-Phase Silent Diesel Generator with Electric Start & 140L Fuel Tank Capacity - 30258
Complete your purchase
Useful add-ons for this product.
Titan 55kVA Three-Phase Silent Diesel Generator with Electric Start...
Product details
Product details
The Titan 55kVA three-phase silent diesel generator supplies a power option for commercial sites and workshops with larger electrical demands. Its separate standby and prime ratings help distinguish outage cover from variable-load operation, while the fuel-use figures support planning around the expected load.
Key Features:
- 55kVA standby and 50kVA prime output.
- Intercooled turbocharged four-cylinder diesel engine.
- 140L fuel tank and electric starting.
- Class H alternator insulation, IP23 enclosure rating and operating-condition monitoring.
Specifications:
- Model: LSY55S3
- Generator type: Silent diesel generator
- Fuel Type: Diesel
- Starting System: Electric
- Phase: Three-phase
- Frequency: 50Hz
- Rated voltage: 230/400V
- Power factor: 0.8
- Standby output: 55kVA / 44kW
- Prime output: 50kVA / 40kW
- Rated speed: 1,500rpm
Engine Specifications:
- Engine model: TITAN Y4102ZLD-C022
- Engine configuration: 4-cylinder, in-line, intercooled turbocharged diesel engine
- Bore × stroke: 102 × 118mm
- Displacement: 3.875L
- Compression ratio: 18:1
- Rated engine power: 48kW
- Lubricating-oil capacity: 13L
- Starting batteries: 2
Fuel & Operating Data:
- Fuel consumption at 25% load: 4.58L/h
- Fuel consumption at 50% load: 6.71L/h
- Fuel consumption at 75% load: 8.52L/h
- Fuel consumption at 100% load: 10.8L/h
- Fuel-tank capacity: 140L
Alternator & Load Characteristics:
- Alternator: 4-pole brushless rotating-field design with permanent-magnet pilot exciter
- Voltage regulator: Solid-state Volts/Hz
- Voltage sensing: three-phase
- Voltage regulation: ±0.25%
- Insulation: Class H insulation
- Alternator enclosure: IP23 enclosure
- One-step load response: Accepts a 100% rated one-step load
- Unbalanced-load support: supports unbalanced load up to the standby rating
Controller Monitoring:
- Voltage
- Current
- Frequency
- Power
- Running hours
- Engine speed
- Coolant temperature
- Oil pressure
- Battery voltage
Protection Functions:
- Overspeed
- Low oil pressure
- High coolant temperature
- Over/under voltage
- Over/under frequency
- Overload
- Short circuit
- Charging failure
Dimensions & Weight:
- Dimensions: 2,460 × 1,006 × 1,255mm
- Net weight: 1,170kg
