Telwin Technology 238 XT CE/MPGE 200A MMA & TIG DC Inverter Welding Machine 230V with Aluminium Case - TEL-816252

The Telwin Technology 238 XT CE/MPGE MMA & TIG DC Inverter Welding Machine with Aluminium Case (TEL-816252) is a professional 230V single-phase DC inverter welder supporting both MMA stick welding and TIG scratch-start arc ignition with an adjustable current range of 5–200A. Rated at 200A at 35% duty cycle and 140A at 60% duty cycle, it features the CE configuration designed for cellulosic electrodes alongside the MPGE Multi Protection for Generator system for reliable operation with compatible generators from 10kW. With adjustable Arc Force and Hot Start, Anti-Stick, a digital welding-current display, 50mm quick connectors, and an IP23 protection rating, it is supplied in a robust aluminium carry case and supports cellulosic, rutile, basic, stainless steel, cast iron, and suitable aluminium electrodes.

Key Features:

• CE Configuration for Cellulosic Electrodes — Specifically configured for reliable cellulosic electrode welding for pipeline and vertical-down welding applications, in addition to standard electrode types.
• MMA & TIG Scratch-Start Dual Process — Supports both MMA stick welding and TIG scratch-start ignition for versatility across professional fabrication, pipeline, and construction welding tasks.
• 5–200A Adjustable Welding Current — Wide current range for precise control from thin sheet metal through to structural and pipeline components.
• MPGE Multi Protection for Generator — Generator protection system ensures reliable, safe operation with compatible generators from 10kW with ±15% voltage variation tolerance.
• Digital Welding-Current Display — Clear digital display for precise current monitoring and parameter setting.
• Broad Electrode Compatibility — Supports cellulosic, rutile, basic, stainless steel, cast iron, and suitable aluminium electrodes from 1.6mm to 4mm.
• Adjustable Arc Force & Hot Start — Fine-tunable arc control functions for optimised arc stability and electrode ignition, particularly important for cellulosic electrode welding.
• Anti-Stick Function — Reduces output current if the electrode sticks, protecting the electrode and workpiece.
• 50mm Quick Connectors — Standard 50mm quick-connect cable connectors for fast, secure welding cable attachment.
• Supplied with Aluminium Case — Robust aluminium carry case for professional transport and storage protection.

Technical Specifications:

• Product Type: MMA and TIG DC Inverter Welding Machine
• Welding Processes: MMA and TIG
• Welding Current Type: Direct Current
• TIG Ignition: Scratch Start
• Mains Voltage: 230V Single Phase
• Mains Frequency: 50/60Hz
• Welding-Current Range: 5–200A
• Maximum Rated Output: 200A at 35% Duty Cycle
• Output at 60% Duty Cycle: 140A
• Maximum No-Load Voltage: 80V
• Maximum Absorbed Current: 39A
• Absorbed Current at 60%: 20A
• Maximum Absorbed Power: 6.3kW
• Absorbed Power at 60%: 3kW
• Minimum Generator Power: 10kW
• Permitted Generator Voltage Variation: ±15%
• Efficiency: 87%
• Power Factor: 0.7
• Electrode Diameter Range: 1.6–4mm
• Compatible Electrodes: Rutile, Basic, Stainless Steel, Cast Iron, Cellulosic and Suitable Aluminium Electrodes
• MMA Functions: Adjustable Arc Force, Adjustable Hot Start and Anti-Stick
• Cable Connectors: 50mm Quick Connectors
• Protection Rating: IP23
• Dimensions: 37.5 × 50 × 22cm
• Weight: 10.55kg

The Telwin Technology 238 XT CE/MPGE is the most versatile model in the Technology XT series, adding cellulosic electrode support and a digital display to the 200A platform for pipeline, structural, and professional fabrication welding. Its CE/MPGE dual configuration, adjustable Arc Force and Hot Start, and broad electrode compatibility including aluminium make it the preferred choice for professionals requiring cellulosic electrode capability alongside standard MMA and TIG welding. Supplied with an aluminium carry case, it is a comprehensive, portable professional welding solution built to Telwin's exacting standards.
