Telwin Mastermig 270/2 Professional 240A MIG-MAG & Brazing Welding Machine 230V/400V - TEL-821065

The Telwin Mastermig 270/2 Professional MIG-MAG & Brazing Welding Machine (TEL-821065) is a versatile 230V/400V three-phase DC MIG-MAG and MIG Brazing welding system delivering an adjustable welding current of 28–240A with both continuous and spot welding modes. Rated at 240A at 30% duty cycle, 160A at 60% duty cycle, and 130A continuously at 100% duty cycle, it supports steel (0.6–1.2mm), stainless steel (0.8–1mm), aluminium (0.8–1mm), and brazing wire (0.8–1mm) across a wire-speed range of 1.5–20m/min. With 10 voltage-adjustment steps, a 2+2 roller wire-feed system, and a 0.9 power factor, it is engineered for general metal fabrication, automotive bodywork, sheet-metal fabrication, stainless steel, and high-strength-steel welding applications.

Key Features:

• MIG-MAG & MIG Brazing — Supports both MIG-MAG welding and MIG Brazing for galvanised and coated sheet metal with minimal zinc burn-off, ideal for automotive bodywork and panel repairs.
• Continuous & Spot Welding Modes — Selectable continuous seam welding and spot welding modes for versatility across fabrication and bodywork applications.
• 28–240A Adjustable Welding Current — Wide current range for precise control from thin sheet metal through to heavier structural components.
• 240A at 30% / 160A at 60% / 130A at 100% — Flexible duty cycle ratings for both burst and sustained welding applications.
• 10 Voltage-Adjustment Steps — 10 selectable voltage steps for precise arc tuning across different wire types, diameters, and material thicknesses.
• Wide Wire Compatibility — Supports steel (0.6–1.2mm), stainless steel (0.8–1mm), aluminium (0.8–1mm), and brazing wire (0.8–1mm).
• 2+2 Roller Wire-Feed System — Four-roller drive (2+2 configuration) ensures consistent, reliable wire feeding across the full wire-speed range of 1.5–20m/min.
• Large Wire-Reel Capacity — Accepts wire reels from 200mm to 300mm diameter for extended production runs.
• 0.9 Power Factor — Near-unity power factor minimises reactive power draw for efficient mains power utilisation.
• 230V/400V Three-Phase Input — Wide voltage input with -25% to +15% tolerance for compatibility with variable site and workshop power supplies.

Technical Specifications:

• Product Type: MIG-MAG and Brazing Welding Machine
• Welding Processes: MIG-MAG and MIG Brazing
• Welding Modes: Continuous and Spot Welding
• Welding Current Type: Direct Current
• Mains Voltage: 230V/400V, Three Phase
• Mains Frequency: 50/60Hz
• Mains-Voltage Tolerance: -25% to +15%
• Welding-Current Range: 28–240A
• Maximum Rated Current: 240A at 30% Duty Cycle
• Welding Current at 60%: 160A
• Continuous Output at 100%: 130A
• MIG Output-Voltage Range: 9–26V
• Maximum No-Load Voltage: 37.3V
• Maximum Absorbed Current at 230V: 25A
• Maximum Absorbed Power: 9kW
• Absorbed Power at 60%: 5.5kW
• Recommended Fuse at 230V: 16A
• Power Factor: 0.9
• Voltage-Adjustment Steps: 10
• Steel-Wire Diameter: 0.6–1.2mm
• Stainless-Steel Wire Diameter: 0.8–1mm
• Aluminium-Wire Diameter: 0.8–1mm
• Brazing-Wire Diameter: 0.8–1mm
• Wire-Speed Range: 1.5–20m/min
• Wire-Reel Diameter: 200–300mm
• Wire-Feed Rollers: 2 + 2
• Feed-Roller Type: F
• Feed-Roller Diameter: 30mm
• Supply-Cable Length: 3.5m
• Insulation Class: H
• Protection Rating: IP22
• Dimensions: 87 × 45.3 × 80cm
• Weight: 66kg

The Telwin Mastermig 270/2 is a professional MIG-MAG and MIG Brazing welding machine that combines 240A output, continuous and spot welding modes, and broad wire compatibility in a robust three-phase unit. Its 10-step voltage adjustment, 2+2 roller wire feed, and 0.9 power factor make it a precise, efficient, and versatile choice for general fabrication, automotive bodywork, sheet-metal, stainless steel, and high-strength-steel welding. A dependable, professional-grade MIG welding solution built to Telwin's exacting standards.
