Lincoln Electric OPTIMARC CV/CC 505 500A Multi-Process Inverter Wel...
Lincoln Electric OPTIMARC CV/CC 505 500A Multi-Process Inverter Welding Machine is available on backorder and will be fulfilled once restocked.
Product details
Product details
The Lincoln Electric OPTIMARC CV/CC 505 is a 500A multi-process inverter welding power source delivering both Constant Voltage and Constant Current output from a 380–415V three-phase supply. It supports MIG/MAG, gas-shielded and self-shielded flux-cored, SMAW/MMA stick and Touch-Start TIG welding, making it a versatile solution for structural fabrication, heavy machinery manufacturing, shipbuilding and petrochemical work. With a 500A output at 60% duty cycle and a 390A continuous rating at 100% duty cycle, it is built for sustained heavy-duty industrial use.
Key Features:
- Supports MIG/MAG (GMAW) welding with constant voltage output
- Supports gas-shielded (FCAW-G) and self-shielded (FCAW-S) flux-cored welding
- Supports SMAW/MMA stick welding with constant current output
- Supports Touch-Start TIG (GTAW) welding with constant current output
- Accepts solid and flux-cored wires from 0.8mm to 2.0mm diameter
- Accepts stick electrodes up to 6mm diameter
- 500A output at 60% duty cycle; 390A continuous output at 100% duty cycle
- Digitally controlled inverter technology for precise arc performance
Specifications:
- Input Supply: 380–415V AC, ±10%, Three Phase, 50/60Hz
- Maximum Input Power: 23kVA at 60% Duty Cycle
- Maximum Welding Output: 500A
- Continuous Rated Output: 390A at 100% Duty Cycle
- Output Type: DC
- MIG/MAG Output Range: 50–500A / 16–39V
- Stick Output Range: 15–500A / 20.6–40V
- TIG Output Range: 5–500A / 10.2–30V
- Supported Wire Diameters: 0.8–2.0mm
- Maximum Stick-Electrode Diameter: 6mm
- Dimensions: 540 × 340 × 800mm
- Net Weight: 47kg
- Operating Temperature: −10°C to +40°C
