Victron Energy SmartSolar MPPT 250/100-tr VE.can Charge Controller ...
Victron Energy SmartSolar MPPT 250/100-tr VE.can Charge Controller - SCC125110411 is backordered and will ship as soon as it is back in stock.
Description
Description
Unlock the full potential of your solar infrastructure with the Victron Energy SmartSolar MPPT 250/100-Tr VE.Can (SCC125110411). This high-voltage, high-current MPPT charge controller is engineered for advanced solar systems where performance and reliability are non-negotiable.
Harnessing Victron’s ultra-fast MPPT algorithm, it dynamically tracks and captures the maximum energy from your solar array—even under partial shading or fluctuating light conditions. It’s ideal for large off-grid, hybrid, or industrial setups. With VE.Can connectivity, programmable control, and robust protection features, it offers both power and control in one advanced package.
Key Features:
- Ultra-fast MPPT algorithm — optimizes energy capture under variable light and shading
- VE.Can & VE.Direct communication ports, plus Bluetooth support, for remote monitoring and control
- 100A continuous charge current — built for high-demand solar systems
- Supports 12V / 24V / 48V automatic voltage detection (36V selectable)
- High input voltage tolerance — up to 250V open-circuit under cold conditions; ~245V operating start limit
- Outstanding efficiency — maximum conversion efficiency exceeds 99%
- Low self-consumption — less than ~35 mA at 12V; ~20 mA at 48V
- Adaptive multi-stage charge algorithm — supports multiple battery types (lead-acid, lithium, etc.)
- Comprehensive protections — such as PV reverse polarity, output short-circuit, over-temperature, reverse current
-
Parallel synchronization — up to 25 units via VE.Can and up to 10 units via Bluetooth
Technical Specifications:
- Battery voltage compatibility (auto-detect): 12V / 24V / 48V; 36V selectable manually
- Rated charge current: 100A continuous
-
Nominal PV power capacity:
• ~1,450W (12V)
• ~2,900W (24V)
• ~5,800W (48V) - Maximum PV open-circuit voltage (Voc): 250V (absolute) / ~245V operating start limit
- Self-consumption (idle): < ~35 mA @ 12V; ~20 mA @ 48V
-
Default charge voltages (absorption / float / equalization):
Absorption: 14.4 / 28.8 / 57.6 V, etc. (adjustable)
Float: 13.8 / 27.6 / 55.2 V (adjustable)
Equalization: 16.2 / 32.4 / 64.8 V (adjustable) - Operating temperature range: –30 °C to +60 °C (full rated output up to ~40 °C)
- Protection ratings & enclosures: IP43 for electronics, IP22 for connections; rugged design for demanding environments
- Parallel synchronization: Up to 25 controllers via VE.Can; 10 via Bluetooth
- Terminal capacity (Tr models): supports up to 35 mm² / AWG2 connections
-
Dimensions (Tr model): 185 × 250 × 95 mm; Weight: ~3 kg
The Victron Energy SmartSolar MPPT 250/100-Tr VE.Can (SCC125110411) is designed for heavy-duty solar systems where maximum output, smart control, and dependable protection matter. With 100A capacity, broad compatibility, efficient energy conversion, and remote management capabilities, it’s a top-tier solution for industrial, commercial or large off-grid installations.
